GCP 25-6-130Doméstico
Circulation pump GCP 25-6-130
220 VVoltage 93 WPower 55 l/minPerformance
Circulation pump for open and closed heating systems: the wet rotor and overheat protection give it a long working life.
Descrição
GIGANT circulation pump GCP 25-6-130 provides forced circulation of the heat transfer fluid in open and closed heating systems. It is fitted with an overheat protection device, which ensures a long service life. The rotor runs in the liquid, which keeps it cool.
Especificações
| Series | GCP |
|---|---|
| Type | Circulation |
| Kind | For specialized work |
| Design | Centrifugal |
| Rotor | Wet |
| Voltage | 220 V |
| Power | 93 W |
| Performance | 55 l/min |
| Housing material | Cast iron |
| Capability adjustment | Yes |
| Mounting length | 130 mm |
| Max lift height | 6 m |
| Pressure | 10 atm |
| Pipe connection, inlet | 1 inch |
| Pipe connection output | 1 inch |
| Protection from dry stroke | No |
| For increase pressure | No |
| Min temperature liquid | 0 °C |
| Max temperature liquid | 110 °C |
| Noise level | 45 dB |
| For warm floor | No |
| For domestic hot water | No |
| For heating boilers | No |
| For towel warmers | No |
| Frequency control | No |
| Temperature sensor | No |
| Recommended diameter pipes | 25 mm - 1" |
| Twin | No |
| Class protection | IP44 |
| Connector V kit | No inch |
| Net weight | 2.4 kg |
Conteúdo da embalagem
- Pump - 1 pc.
- Union nuts - 2 pcs.
- Rubber gaskets - 2 pcs.
- Operating manual - 1 pc.
Embalagem
| Peso | 2 kg |
|---|
